Building JAX Core from Scratch with Autodidax

If you’ve ever been curious about how JAX works under the hood but found its implementation daunting, this tutorial is for you. By diving into "Autodidax," a simplified version of JAX’s core system, you’ll gain insights into the fundamental ideas and jargon used in JAX. This article covers Part 1, focusing on transformations as interpreters, including standard evaluation, jvp, and vmap.

Transformations as Interpreters

In JAX, functions are transformed by interpreting them differently. Instead of just applying primitive operations to numerical inputs to produce outputs, we can override these primitives to let different values flow through the program. For example, instead of computing the result directly, we might compute its derivative (JVP) or vectorize it (vmap).

Consider a simple function:

def f(x):
  y = sin(x) * 2.
  z = -y + x
  return z

Here, sin, multiplication (*), addition (+), and negation (-) are primitive operations. JAX allows us to transform this function by interpreting these primitives in different ways.

Core Machinery

To implement transformations, we need a way to intercept and override the application of these primitives. We start by defining them as Primitive objects:

from typing import NamedTuple

class Primitive(NamedTuple):
  name: str

add_p = Primitive('add')
mul_p = Primitive('mul')
neg_p = Primitive('neg')
sin_p = Primitive('sin')
cos_p = Primitive('cos')
reduce_sum_p = Primitive('reduce_sum')
greater_p = Primitive('greater')
less_p = Primitive('less')
transpose_p = Primitive('transpose')
broadcast_p = Primitive('broadcast')

def add(x, y): return bind1(add_p, x, y)
def mul(x, y): return bind1(mul_p, x, y)
def neg(x): return bind1(neg_p, x)
def sin(x): return bind1(sin_p, x)
def cos(x): return bind1(cos_p, x)

The bind1 function is a placeholder for the actual binding logic that will apply the primitive with the given inputs. This setup allows us to intercept and transform the application of these primitives.

Standard Evaluation

In standard evaluation, we simply apply the primitive operations as they are defined:

def bind1(prim, *args):
  if prim == add_p:
    return args[0] + args[1]
  elif prim == mul_p:
    return args[0] * args[1]
  elif prim == neg_p:
    return -args[0]
  # Add more primitives as needed

This is the default behavior, but we can override it for transformations.

JVP (Jacobian-Vector Product)

The JVP transformation computes the derivative of a function. Instead of applying the primitive directly, we apply its JVP rule:

def bind1(prim, *args):
  if prim == add_p:
    return args[0] + args[1], (1, 1)
  elif prim == mul_p:
    return args[0] * args[1], (args[1], args[0])
  # Add more primitives as needed

Here, the second element of each tuple represents the derivative with respect to each input. This allows us to compute derivatives while evaluating the function.

Vmap (Vectorization)

The vmap transformation vectorizes a function to handle batched inputs. For example, if we have an array of inputs, we can apply the function to each element in the array:

def bind1(prim, *args):
  if prim == add_p:
    return jnp.vectorize(add)(args[0], args[1])
  elif prim == mul_p:
    return jnp.vectorize(mul)(args[0], args[1])
  # Add more primitives as needed

This allows us to handle batched inputs efficiently.

Stacks of Interpreters

JAX can compose multiple transformations, leading to stacks of interpreters. For example, we might want to compute the JVP and then vectorize the result:

def transformed
