Exploring GPT-4o's Structured Outputs for AI-Assisted Web Scraping

I'm pretty excited about the new structured outputs feature in OpenAI’s API, so I decided to take it for a spin and develop an AI-assisted web scraper. This post summarizes my learnings and shares some interesting findings.

Asking GPT-4o to Scrape Data

The first experiment was straightforward: I asked GPT-4o to extract data from an HTML string using the new structured outputs feature. To structure the output, I used the following Pydantic models:

from typing import List, Dict
from pydantic import BaseModel

class ParsedColumn(BaseModel):
    name: str
    values: List[str]

class ParsedTable(BaseModel):
    name: str
    columns: List[ParsedColumn]

The system prompt I used was:

You’re an expert web scraper. You’re given the HTML contents of a table and you have to extract structured data from it.

Here are some interesting things I found when parsing different tables:

• Note: I also tried GPT-4o mini, but it yielded significantly worse results, so I continued my experiments with GPT-4o.

Parsing Complex Tables

After experimenting with simple tables, I wanted to see how the model would handle more complex ones. I passed a 10-day weather forecast from Weather.com, which contains a large row at the top and smaller rows for the other nine days. Interestingly, GPT-4o was able to parse this correctly:

For the remaining nine days, the table shows both day and night forecasts (see screenshot above). The model correctly parsed this data and added a Day/Night column. Here’s how it looks in the browser (note that you need to click on the button to the right of each row to display this):

At first, I thought the parsed Condition column was a hallucination because I didn’t see it on the website. However, upon inspecting the source code, I realized these tags exist but are invisible in the table.

Combined Rows Break the Model

When thinking about where to find "easy tables," my first thought was Wikipedia. Surprisingly, a seemingly simple table from the Human Development Index page breaks the model because rows with repeated values are merged:

While the model is able to retrieve individual columns (as instructed by the system prompt), they don’t have the same size, making it impossible to represent the data as a table.

I tried modifying the system prompt with the following:

Tables might collapse rows into a single row. If that’s the case, extract the collapsed row as multiple JSON values to ensure all columns contain the same number of rows.

Unfortunately, this didn’t work. I have yet to try further modifications to the system prompt to instruct the model to extract rows instead of columns.

Asking GPT-4o to Return XPaths

Running an OpenAI API call every time can become very expensive, so I decided to ask the model to return XPaths (a language for selecting nodes in XML documents) instead. This way, you can use a traditional web scraping library to extract data based on the provided XPaths.

Here’s how I modified the system prompt:

You’re an expert web scraper. Given the HTML contents of a table, provide the XPath expressions needed to extract each column's values.

This approach reduces the number of API calls and leverages the model’s ability to understand complex HTML structures without incurring the cost of multiple requests.

Conclusions and Demo

Overall, GPT-4o’s structured outputs feature shows great promise for AI-assisted web scraping. While it has some limitations, especially with merged rows, it can handle complex tables quite well. If you’re interested, you can check out the demo and source code to see how it works in action.
