If you've been working with Large Language Models (LLMs) on your MacBook and found that parallel inference is lacking, there's good news. I recently developed ParaLLM, a solution for fast parallel LLM inference using MLX. This approach leverages batched key-value (KV) caching to significantly boost throughput, especially useful for generating multiple outputs at once.

The Problem with Single-Stream Inference

For single-stream applications like chat interfaces, tools like llama.cpp and MLXServer perform well on Apple devices. However, when you need to sample a large number of outputs simultaneously-such as for evaluating training runs or developing "agent-flavored" applications-these tools fall short in terms of total throughput.

On CUDA machines, solutions like vLLM offer high tok/s throughput with parallel requests, but they don't work on Macs. This is where ParaLLM comes in.

Batched KV Caching: The Key to Parallel Inference

The main feature enabling this speedup is batched key-value caching. By extending the generate method from the existing mlx_lm library, I introduced a BatchedKVCache object and a batch_generate method to handle multiple decoding channels.

Implementation Details

• Model Loading: ParaLLM uses the same model loading mechanism as MLX.
• Batch Generation:
  • load Function: Loads the model and tokenizer.
  • batch_generate Method: Generates multiple outputs in parallel using batched KV caching.

Here's a sample code snippet to illustrate how it works:

from mlx_parallm.utils import load, generate, batch_generate

Fun trick for generating workloads

import string capital_letters = string.ascii_uppercase distinct_pairs = [(a, b) for i, a in enumerate(capital_letters) for b in capital_letters[i + 1:]] prompt_template = "Think of a real word containing both the letters {l1} and {l2}. Then, say 3 sentences which use the word." prompts_raw = [prompt_template.format(l1=p[0], l2=p[1]) for p in random.sample(distinct_pairs, 325)]

model, tokenizer = load("google/gemma-1.1-2b-it") responses = batch_generate(model, tokenizer, prompts=prompts_raw, max_tokens=100, verbose=True, temp=0.0)

### Performance Benchmarks

For "small" models like Gemma-2B, ParaLLM achieves **1600+ tokens/sec** in total throughput on a 128GB M3 Max MacBook. This is a significant improvement over single-stream generation.

### Supported Models and Future Work

I've tested ParaLLM with the following models:
- **Gemma-2B**
- **Phi-3-mini**
- **Llama3-8B**

All of these models show substantial throughput gains, especially as you increase the number of parallel requests.

### Additional Features

While features like repetition penalties and streaming outputs are not yet supported, I plan to contribute a `batch_generate` PR for mlx_lm once it reaches a stable, non-breaking state. In the meantime, adding other models is straightforward:
- **Copy Architecture Files**: Copy the necessary architecture files from `mlx_lm/models` into `mlx_parallm/models`.
- **Replace KVCache References**: Replace any `KVCache` references with `BatchedKVCache`.

### Conclusion

ParaLLM brings high-throughput parallel LLM inference to Mac users, making it a valuable tool for evaluating training runs and developing [complex](/articles/sglang-and-radixattention-accelerating-complex-llm-workloads-with-efficient-kv-cache-reuse) applications. The code is available on GitHub at [mlx_parallm](https://github.com/willccbb/mlx_parallm/tree/main), and I encourage you to try it out and provide feedback.
