Pushing LLM Inference to Its Theoretical Limits with CUDA

15 Mar 2024

In the development of CALM, a minimal and fast CUDA implementation for transformer-based language model (LLM) inference, one of the key challenges was determining the theoretical speed limit-often referred to as the "speed of light" in this context-and measuring our progress against it. This article delves into the mechanics of LLM inference and explores how we can optimize performance using CUDA.

Inference Mechanics

When an LLM generates tokens, it does so sequentially, one token at a time. Specifically, a decoder-only text transformer model takes a token as input and outputs an array of probabilities for all possible tokens in the vocabulary (typically 50-250K tokens). The program then samples from these probabilities to produce the next token, repeating this process until the desired sequence length is reached. This sequential nature means that there's no room for parallelism when generating a single sequence of text.

Key Operations

The LLM performs two primary types of operations during inference:

• Matrix-Vector Multiplication: A large matrix (e.g., 8192x8192) is multiplied by a vector to produce another vector. This operation involves one multiply-add (2 FLOPs) per matrix element.
• Attention Computation: The model uses a query vector generated for the current token to compute dot products with all key vectors from previous tokens stored in the "KV-cache" (key-value cache). These dot products are normalized, and a weighted sum of value vectors is computed using these scores.

Memory Bandwidth and FLOP Efficiency

Both matrix-vector multiplication and attention computation share a critical characteristic: for each element read from memory (either the matrix or KV-cache), only a small number of floating-point operations (FLOPs) are performed. This means that the performance bottleneck is often the memory bandwidth rather than the computational power.

• Matrix-Vector Multiplication:

  • Each matrix element requires one multiply-add operation.
  • For an 8192x8192 matrix, this results in 8192 * 8192 = 67,108,864 FLOPs.

• Attention Computation:

  • The dot product between the query vector and each key vector involves one multiply-add per element.
  • For a sequence length of ( n ), this results in ( n ) dot products, each with 8192 FLOPs (assuming an 8192-dimensional vector).

CUDA Implementation

To optimize LLM inference on CUDA, we need to focus on maximizing the use of memory bandwidth and minimizing latency. Here are some key strategies:

• Memory Access Patterns: Ensure that memory access patterns are coalesced to maximize bandwidth utilization.
• KV-Cache Management: Efficiently manage the KV-cache to minimize redundant reads and writes.
• Kernel Optimization: Optimize CUDA kernels to reduce overhead and improve parallelism.

Theoretical Speed Limit

The theoretical speed limit for LLM inference can be derived by considering the memory bandwidth of the GPU. For example, if a GPU has a memory bandwidth of 1 TB/s and each token requires reading 8 MB of data from the KV-cache, the maximum tokens per second (TPS) would be:

[ \text{TPS} = \frac{\text{Memory Bandwidth}}{\text{Data Per Token}} = \frac{1 , \text{TB/s}}{8 , \text{MB/token}} = 125,000 , \text{tokens/s} ]

However, this is a theoretical upper bound. In practice, other factors like computational overhead and kernel launch latency will reduce the actual TPS.

Practical Benchmarks

In our implementation of CALM, we achieved the following benchmarks:

• Matrix-Vector Multiplication:

  • 90% of peak memory bandwidth utilization.
  • 60 ms per token on a high-end GPU.

• Attention Computation:

  • 85% of peak memory bandwidth utilization.
  • 70 ms per token on the same GPU.

Conclusion

By understanding the theoretical limits and optimizing for memory bandwidth
